SDLVA-1G20G-58-12-SFF

Stock Availability: 0

SDLVA-1G20G-58 Quantic PMI
Enlarge

Product image for reference only. For precise specifications, refer to datasheet.

Manufacturer: Quantic PMI
Mfg #: SDLVA-1G20G-58-12-SFF
Richardson RFPD #: SDLVA-1G20G-58
Description: Successive Detection Log Video Amplifier Module
Min/Mult: 1
Datasheet SDLVA-1G20G-58 Data Sheet
EDA/CAD Models

Quantic PMI Model SDLVA-1G20G-58-12-SFF is a 1 to 20 GHz Successive Detection Log Video Amplifier (SDLVA) . Excellent performance is packed into this ultra-small package. Its ultra-wide frequency range and 59 dB dynamic range makes this part suitable for a multitude of applications. A key feature is its low power consumption of 1.2 W and a single operating voltage of +12 V. Supplied in Quantic PMI standard PE2 housing (1.08" x 0.71" x 0.29") that can be used as a SMA connectorized or surface mount component.

Key Attributes Value Search Similar
Input Minimum Frequency (MHz) 1000
Input Maximum Frequency (MHz) 20000
Maximum Logging Range (dBm) 5
Minimum Logging Range (dBm) -55
Return Loss (dB) 6
Log Video Maximum Output Voltage (V) 1.5
Log Video Minimum Output Voltage (V) 0.9
Minimum Supply Voltage (V) 12
Maximum Supply Voltage (V) 15
Supply Current (mA) 100

Datasheets

  SDLVA-1G20G-58

Stock

 Request Quote for Lead Time

Order

 Pricing in (USD)
Unit Price:
1:  $5,069.9300
2:  $5,019.1800
5:  $4,968.4300
10:  Get Quote


Please notify me when stock becomes available!
